2329

Product Specs

• Product Details
  •

    ESD Safe	No
    Series	15 Series, 30 Series, 40 Series, 45 Series
    Material	Black Polyurethane Wheel on Polyolefin Core
    A	4.724” (120.00mm)
    B	3.150” (80.00mm)
    C	.335” (8.50mm)
    D	.787” (20.00mm)
    E	1.575” (40.00mm)
    F	4.000” (101.60mm)
    G	5.079” (129.00mm)
    H	.138” (3.50mm)
    Load Capacity	350 lbs (158.75 kg)
    Weight	1.250000

• Description

  • • Directly mount to T-Slot with no base plate required
    • Compatible with 80/20 T-Slot profile series 15, 30, 40, 45
    • Max Load Capacity: 350 lbs
    • Temperature Rating: -20° to 180° F
    • Wheel Material: Polyurethane Tread on Polyolefin Core
    • Wheel Style: 4” Diameter x 1.23” wide
    • Wheel Durometer: 60 (+/-5) Shore D
    • Bearing Type: Precision Ball Bearing

• Sugg. Hardware

  • Mount to T-Slot

    Series	Part Number	Qty	Description
    	3340	2	5/16-18 x .500" Flanged Button Head Socket Cap Screw (FBHSCS)
    	3278	2	5/16-18 Slide-in Economy T-Nut - Offset Thread
    	11-8312	2	M8 x 12.00mm Button Head Socket Cap Screw (BHSCS)
    	30-3796	2	M8 Slide-in Economy T-Nut - Centered Thread
    	11-8312	2	M8 x 12.00mm Button Head Socket Cap Screw (BHSCS)
    	3838	2	M8 Slide-in Economy T-Nut - Offset Thread
    	11-8312	2	M8 x 12.00mm Button Head Socket Cap Screw (BHSCS)
    	13049	2	M8 Self-Aligning Slide-in T-Nut
