Proactive Protection

Custom Machine Guard

It’s a struggle to find machine guards that adequately protect personnel and equipment from risk and comply with all OSHA and government regulations, without interfering with workflow. A custom guard can meet all of these requirements, with the added benefit of being modular to accommodate change.

Custom Machine Guard

This 80/20 barrier guard is designed to frame a conveyor and robotic arm – it’s built in segments that are easy to reconfigure as processes evolve. Tailor your machine guard to fit your exact requirements.

XDIY1804 Add Safety Devices

T-slot channel makes it easy to move and reposition stop switches and sensors.

XDIY1804 Wire Mesh Panels

Provide ventilation and airflow with a thermoplastic coating to avoid injury.

XDIY1804 Modular Design

Build in subassemblies for fast reconfiguration.

XDIY1804 Safety Yellow Profiles

Denote caution and warning with yellow powder-coat stock profiles.

Click to download DIY Guide

Download FREE

Drawing Files & Bill of Materials!

  • Download AutoCAD Files
  • Download SolidWorks Files
  • Download IGES Files
  • Download BOM Files
  • Download eDrawing Files
