25-2750-Black
25 Series Dual Roller Wheel Bracket
25 Series Dual Roller Wheel Bracket
The dual roller wheel bracket is made of anodized aluminum and mounts to a T-slot profile. It is commonly used with roller wheels to form assemblies that create door frames, linear glides, and track systems. The mounting hardware is included.
| ESD Safe | No |
| Series | 25 Series |
| Material | Aluminum |
| Grade | 6063-T6 |
| Finish | Anodize |
| Color | Black |
| Process | Milled |
| A | 25.40mm |
| B | 12.70mm |
| C | 12.70mm |
| D | 47.50mm |
| E | 17.00mm |
| F | 5.81mm |
| G | 13.81mm |
| H | M6 X 1.0 |
| J | M6 X 1.0 |
| K | 6.40mm |
| L | 20.42mm |
| M | 78.00mm |
| N | 23.44mm |
| P | 31.10mm |
| Q | 12.70mm |
| Weight | 0.120800 |
The dual roller wheel bracket is made of anodized aluminum and mounts to a T-slot profile. It is commonly used with roller wheels to form assemblies that create door frames, linear glides, and track systems. The mounting hardware is included.
Product Specs
- Product Details
-
ESD Safe No Series 25 Series Material Aluminum Grade 6063-T6 Finish Anodize Color Black Process Milled A 25.40mm B 12.70mm C 12.70mm D 47.50mm E 17.00mm F 5.81mm G 13.81mm H M6 X 1.0 J M6 X 1.0 K 6.40mm L 20.42mm M 78.00mm N 23.44mm P 31.10mm Q 12.70mm Weight 0.120800
-
- Description
The dual roller wheel bracket is made of anodized aluminum and mounts to a T-slot profile. It is commonly used with roller wheels to form assemblies that create door frames, linear glides, and track systems. The mounting hardware is included.
-
