15 Series Single Short UniBearing™
15 Series Single Short UniBearing™
The single short UniBearing™ has an open design that enables customized layouts. It is an option that is commonly used in applications with one guiderail. The UniBearing™ is easy to quickly install or remove without taking it apart, allowing reduced retooling and downtime and increased productivity and flexibility. The pads are mounted using stainless steel flathead socket cap screws that secure it to the housing and eliminate the need for high-cycle pads. The bearing can move or be fixed; when fixed, it allows the guardrail and assembly to move. All UniBearings™ come with pre-drilled brake holes and tapped mounting holes that enable attachment of accessories to a flat surface.
The single short UniBearing™ has an open design that enables customized layouts. It is an option that is commonly used in applications with one guiderail. The UniBearing™ is easy to quickly install or remove without taking it apart, allowing reduced retooling and downtime and increased productivity and flexibility. The pads are mounted using stainless steel flathead socket cap screws that secure it to the housing and eliminate the need for high-cycle pads. The bearing can move or be fixed; when fixed, it allows the guardrail and assembly to move. All UniBearings™ come with pre-drilled brake holes and tapped mounting holes that enable attachment of accessories to a flat surface.
Total Price
................................................................................................................................| Series | 15 Series |
| Material | Aluminum |
| Grade | 6005A – T61 |
| Process | Extruded |
| Finish | Anodize |
| Color | Clear |
| A | 3.125" |
| B | .309" |
| C | .120" |
| D | .505" |
| E | .245" |
| F | .485" |
| G | .616" |
| H | 1.625" |
| J | 2.375" |
| K | .656" |
| L | .750" |
| M | 1.500" |
| N | 2.812" |
| P | 5/16 SHCS |
| Q | 5/16-18 |
| R | 10-24 |
| S | .328" |
| Weight | 0.449000 |
The single short UniBearing™ has an open design that enables customized layouts. It is an option that is commonly used in applications with one guiderail. The UniBearing™ is easy to quickly install or remove without taking it apart, allowing reduced retooling and downtime and increased productivity and flexibility. The pads are mounted using stainless steel flathead socket cap screws that secure it to the housing and eliminate the need for high-cycle pads. The bearing can move or be fixed; when fixed, it allows the guardrail and assembly to move. All UniBearings™ come with pre-drilled brake holes and tapped mounting holes that enable attachment of accessories to a flat surface.
Mount to T-Slot
| Series | Part Number | Qty | Description |
|---|---|---|---|
 | 3110 | 2 | 5/16-18 x .625" Socket Head Cap Screw (SHCS) |
| 3279 | 1 | 5/16-18 Double Slide-in Economy T-Nut |
** In accordance with GDPR requirements, in order to download CAD files you will need to sign in to your PartCommunity account below, after clicking Generate. A partCommunity account is separate from your 80/20 account. If you do not have a PartCommunity account, you will need to create a free account.
Product Specs
- Product Details
-
Series 15 Series Material Aluminum Grade 6005A – T61 Process Extruded Finish Anodize Color Clear A 3.125" B .309" C .120" D .505" E .245" F .485" G .616" H 1.625" J 2.375" K .656" L .750" M 1.500" N 2.812" P 5/16 SHCS Q 5/16-18 R 10-24 S .328" Weight 0.449000
-
- Description
The single short UniBearing™ has an open design that enables customized layouts. It is an option that is commonly used in applications with one guiderail. The UniBearing™ is easy to quickly install or remove without taking it apart, allowing reduced retooling and downtime and increased productivity and flexibility. The pads are mounted using stainless steel flathead socket cap screws that secure it to the housing and eliminate the need for high-cycle pads. The bearing can move or be fixed; when fixed, it allows the guardrail and assembly to move. All UniBearings™ come with pre-drilled brake holes and tapped mounting holes that enable attachment of accessories to a flat surface.
-
Incl. Hardware
Mount to T-Slot
Series Part Number Qty Description 3110 2 5/16-18 x .625" Socket Head Cap Screw (SHCS)
3279 1 5/16-18 Double Slide-in Economy T-Nut
