Product Specs

• Product Details
  •

    Series	Fractional, Ready Tube
    Material	Steel
    Grade	Class 8
    Finish	Zinc
    Color	Bright
    Nylock	No
    A	.670"
    B	.500"
    C	5/16-18
    D	.040"
    E	.170"
    F	.275"
    Weight	0.013000
