Two ways to install: Slide into the end of profile or install on captivated profiles with Roll-in T-nut
Left-handed barrel thread to prevent loosening during installation
Holding force exceeding 600 lbs and torsional strength over 500 in-lbs.
Install barrel thread with 6mm ball end power bit (PN 65-6092). Use 5mm ball end hex wrench for screw (PN 65-6098).
