Product Specs

• Product Details
  •

    Series	10 Series
    Material	Aluminum
    Grade	6105-T5
    Process	Extruded
    Finish	Anodize
    Color	Clear
    A	1.968"
    B	.656"
    C	.250"
    D	.094"
    E	1.624"
    F	1.312"
    G	.306"
    H	.156"
    J	1.312"
    K	.311"
    L	1.875"
    M	.938"
    N	.438"
    P	.812"
    Q	1.000"
    R	#8 FHS
    S	.265"
    T	.257"
    U	1.000"
    V	.438"
    W	.343"
    X	.406"
    Weight	0.196000

• Description

  • The 3-slot mount – single flange short standard linear bearing with brake holes is typically used in linear motion applications. It houses profiles with a minimum of three open T-slots, has a single flange and is a shorter option. The bearing includes pads, screws and shims; the pads are made of self- lubricating UHMW. All 80/20 bearings are designed for compression loads only and not intended to support hanging loads.
