15 Series 1" Double Shaft Stanchion Mounting Block
15 Series 1" Double Shaft Stanchion Mounting Block
The double shaft stanchion mounting block is commonly used with the aluminum tube profile to create two additional axes. Tubes connect parallel to the mounted base to form the stanchions. The block is aluminum, making it a strong and durable option. Clamp screws are included. Suggested hardware to mount the base to a T-slot can be found on the "Suggested Hardware" tab.
The double shaft stanchion mounting block is commonly used with the aluminum tube profile to create two additional axes. Tubes connect parallel to the mounted base to form the stanchions. The block is aluminum, making it a strong and durable option. Clamp screws are included. Suggested hardware to mount the base to a T-slot can be found on the "Suggested Hardware" tab.
Related Products
-
Part No. 3470$1.17Bolt Assembly: 5/16-18 x 1.000" Black SHCS with Washer and Slide-In Economy T-Nut - Offset Thread - Black Zinc -
Part No. 3427$1.79Bolt Assembly: 5/16-18 x 2.250" Black SHCS and Slide-In Economy T-Nut - Offset Thread - Black Zinc -
| ESD Safe | Yes |
| Series | 15 Series |
| Material | Aluminum |
| Grade | 6063-T6 |
| Finish | Anodize |
| Color | Clear |
| Process | Milled |
| A | 2.125" |
| B | .312" |
| C | 1.500" |
| D | 6.500" |
| E | .375" |
| F | 2.125" |
| G | 1.500" |
| H | .328" |
| J | 5/16-18 SHCS |
| K | 2.130" |
| L | .330" |
| M | .560" |
| N | 1.000" |
| P | .500" |
| Q | 1.068" |
| R | 5.000" |
| S | .750" |
| T | 3.500" |
| U | 1.004" |
| Weight | 1.857000 |
The double shaft stanchion mounting block is commonly used with the aluminum tube profile to create two additional axes. Tubes connect parallel to the mounted base to form the stanchions. The block is aluminum, making it a strong and durable option. Clamp screws are included. Suggested hardware to mount the base to a T-slot can be found on the "Suggested Hardware" tab.
Stanchion to T-Slot
| Series | Part Number | Qty | Description | ||
|---|---|---|---|---|---|
 | 3470 | 4 | Bolt Assembly: 5/16-18 x 1.000" Black SHCS with Washer and Slide-In Economy T-Nut - Offset Thread - Black Zinc | ||
| And/Or | | 3427 | 4 | Bolt Assembly: 5/16-18 x 2.250" Black SHCS and Slide-In Economy T-Nut - Offset Thread - Black Zinc |
Product Specs
- Product Details
-
ESD Safe Yes Series 15 Series Material Aluminum Grade 6063-T6 Finish Anodize Color Clear Process Milled A 2.125" B .312" C 1.500" D 6.500" E .375" F 2.125" G 1.500" H .328" J 5/16-18 SHCS K 2.130" L .330" M .560" N 1.000" P .500" Q 1.068" R 5.000" S .750" T 3.500" U 1.004" Weight 1.857000
-
- Description
The double shaft stanchion mounting block is commonly used with the aluminum tube profile to create two additional axes. Tubes connect parallel to the mounted base to form the stanchions. The block is aluminum, making it a strong and durable option. Clamp screws are included. Suggested hardware to mount the base to a T-slot can be found on the "Suggested Hardware" tab.
