3959

Product Specs

• Product Details
  •

    ESD Safe	No
    Series	10 Series, 15 Series, 25 Series, 30 Series, 40 Series, 45 Series
    Material	Steel
    Color	Black
    A	.950"
    B	.236"
    C	.475"
    D	.233"
    E	21.654"
    F	23.160"
    G	23.625"
    H	.550"
    Weight	2.062000

• Description

  • The magnetic tool holder is commonly used to organize and store tools. It mounts to a T-slot profile.

• Sugg. Hardware

  • Mount to T-Slot

    Series	Part Number	Qty	Description
    	11-6312	2	M6 x 12.00mm Button Head Socket Cap Screw (BHSCS)
    	3859	2	M6 Slide-in Economy T-Nut - Centered Thread
    	11-6312	2	M6 x 12.00mm Button Head Socket Cap Screw (BHSCS)
    	3931	2	15 & 40 Series M6 Standard Drop-in T-Nut
    	11-6310	2	M6 x 10.00mm Button Head Socket Cap Screw (BHSCS)
    	25-1961	2	M6 Slide-in Economy T-Nut - Centered Thread
    	11-6310	2	M6 x 10.00mm Button Head Socket Cap Screw (BHSCS)
    	13117	2	30 Series M6 Standard Drop-in T-Nut
    	11-6312	2	M6 x 12.00mm Button Head Socket Cap Screw (BHSCS)
    	40-1961	2	M6 Slide-in Economy T-Nut - Centered Thread
    	11-6312	2	M6 x 12.00mm Button Head Socket Cap Screw (BHSCS)
    	13129	2	45 Series M6 Standard Drop-in T-Nut
