2328
45 Series 4 Hole - Concealed Hinge
45 Series 4 Hole - Concealed Hinge
The 4 hole - concealed hinge allows you to design doors with hidden hinges when the door is closed. The hinge mounts to the inside of the frame, which makes enclosures more secure; they are not able to be dismantled when the door is shut.
| ESD Safe | No |
| Series | 45 Series |
| Material | Aluminum |
| Grade | 6060 |
| Finish | Anodize |
| Color | Clear |
| Process | Extruded |
| A | 3.976" |
| B | 1.969" |
| C | 1.181" |
| D | .252" |
| E | 1.063" |
| F | 1.850" |
| G | 3.701" |
| H | .394" |
| J | .157" |
| Weight | 0.062000 |
The 4 hole - concealed hinge allows you to design doors with hidden hinges when the door is closed. The hinge mounts to the inside of the frame, which makes enclosures more secure; they are not able to be dismantled when the door is shut.
Mount to T-Slot
| Series | Part Number | Qty | Description |
|---|---|---|---|
 | 13-6716 | 4 | M6 x 16.00mm Flat Head Socket Cap Screw (FHSCS) |
| 14126 | 4 | M6 Slide-in Economy T-Nut Block |
Product Specs
- Product Details
-
ESD Safe No Series 45 Series Material Aluminum Grade 6060 Finish Anodize Color Clear Process Extruded A 3.976" B 1.969" C 1.181" D .252" E 1.063" F 1.850" G 3.701" H .394" J .157" Weight 0.062000
-
- Description
The 4 hole - concealed hinge allows you to design doors with hidden hinges when the door is closed. The hinge mounts to the inside of the frame, which makes enclosures more secure; they are not able to be dismantled when the door is shut.
- Sugg. Hardware
-
CAD Files
-
