2133
15 Series 5-Hole Rectangular Gasket for Pressure Manifold
15 Series 5-Hole Rectangular Gasket for Pressure Manifold
The 5-hole rectangular gasket for pressure manifold is made of a cork and synthetic rubber combination used to prevent leakage. It is commonly used with manifold plates to completely seal a profile end or create a tight seal where a substance is released.
| ESD Safe | No |
| Series | 15 Series |
| Material | CR-20 |
| Color | Brown |
| A | 1.500" |
| B | .750" |
| C | 1.500" |
| D | .750" |
| E | .750" |
| F | 1.500" |
| G | .750" |
| H | .265" |
| J | .030" |
| K | 4.500" |
| Weight | 0.006000 |
The 5-hole rectangular gasket for pressure manifold is made of a cork and synthetic rubber combination used to prevent leakage. It is commonly used with manifold plates to completely seal a profile end or create a tight seal where a substance is released.
Product Specs
- Product Details
-
ESD Safe No Series 15 Series Material CR-20 Color Brown A 1.500" B .750" C 1.500" D .750" E .750" F 1.500" G .750" H .265" J .030" K 4.500" Weight 0.006000
-
- Description
The 5-hole rectangular gasket for pressure manifold is made of a cork and synthetic rubber combination used to prevent leakage. It is commonly used with manifold plates to completely seal a profile end or create a tight seal where a substance is released.
-
